Turn Drawing Package CHAOS into Actionable info
Construction AI
Construction AI
Chat with your drawing set
Upload a set, pick the sheets that matter to your trade, and ask questions in plain language — counts, schedules, areas and volumes. It reads the legend first, shows its work, and tells you when it can’t read something instead of guessing.
Surveys in. Point clouds out.
Upload a vectorized survey PDF and get back a 3D point cloud in DXF — plus structured XLS and CSV for cross-sections, offsets and elevation data. Straight into your CAD workflow, no manual tracing.
Procore integration demo
Let the computer do the work
Because counting fixtures by hand isn’t the best use of your expertise, and tracing a survey PDF into CAD line by line isn’t why you got into construction. So we built two tools: a chat assistant that reads your drawing set — counts, schedules, areas and volumes, receipts included — and a conversion app that turns vectorized survey PDFs into point clouds, DXF, XLS and CSV in minutes. The repetitive stuff gets handled with calm precision, and your time goes to decisions, not data entry.
Station Labels
-
During preconstruction, drawing packages show up as bloated PDFs — vital data buried in cluttered tables, scattered notes and hard-to-parse geometry. And the questions don’t wait: how many fixtures on Level 1, what’s in the door schedule that isn’t on the plans, how many cubic yards in the north wing slab, and who’s going to trace that survey into CAD. Your team didn’t sign up to squint at cross-sections or retype specs into spreadsheets at 10pm. That’s where Construction AI comes in.
-
Two tools, one goal. The chat assistant at chat.construction.ai reads your drawing set the way a foreman does — counts, schedules, areas and volumes, with the receipts to back them up. The conversion app at app.construction.ai turns vectorized survey PDFs into 3D point clouds — DXF, XLS and CSV — in minutes. No training, no setup, no friction. And our Procore integration (now in beta) highlights what matters directly on the drawings your team already keeps there.
-
-
Founded in 2016, Construction AI started by automating takeoffs at scale — machine learning that pulls MasterFormat codes, quantities, geometry and text out of complex vector PDFs with precision. That work became the conversion app at app.construction.ai: surveys in, point clouds and structured data out. In 2026 we added the chat assistant at chat.construction.ai, so you can ask a drawing set questions in plain language and get answers that show their work. Built for contractors, engineers and estimators across every sector — no setup, no friction, just results.
